Product Description
Cryogenic liquid storage tank is a series of products about first/second/third type pressure vessels manufactured by our company, the products strictly in accordance with the TSG21-2016 <Stationary Type Pressure Vessels Safety Technical Supervision Rules>GB/T150-2011<pressure vessels>, GB/T18442-2019<stationary vacuum insulation cryogenic pressure vessel>,design, manufacture, inspect and accept.
Cryogenic liquid storage tanks is for double wall,vertical (horizontal) structure,adopt vacuum powder insulation,with the advantage of compact structure,low daily evaporation rate,small footprint,centralized control,safe,reliable,easy operation and maintenance.
Product Parameters
| CRYOGENICLIQUIDTANKPARAMETER |
| WorkingPressure(Mpa) | WorkingMedium | Volume(m³) | Weight(kg) | OutsideSize(mm) |
| 0.8 | LOX/LN₂/LAr | 5 | 4160 | Φ1900×5115 |
| 0.8 | LOX/LN₂/LAr | 10 | 6035 | Φ2200×6035 |
| 0.8 | LOX/LN₂/LAr | 15 | 8196 | Φ2300×7730 |
| 0.8 | LOX/LN₂/LAr | 20 | 9715 | Φ2600×7655 |
| 0.8 | LOX/LN₂/LAr | 30 | 13270 | Φ2600×10605 |
| 0.8 | LOX/LN₂/LAr | 50 | 21725 | Φ3200×11670 |
| 0.8 | LOX/LN₂/LAr | 100 | 43386 | Φ3600×16550 |
| 0.8 | LOX/LN₂/LAr | 150 | 61500 | Φ3800×22000 |
| 0.8 | LOX/LN₂/LAr | 200 | 76800 | Φ4000×25300 |
| 1.6 | LOX/LN₂/LAr | 5 | 4650 | Φ1900×5115 |
| 1.6 | LOX/LN₂/LAr | 10 | 6850 | Φ2200×6035 |
| 1.6 | LOX/LN₂/LAr | 15 | 9780 | Φ2300×7730 |
| 1.6 | LOX/LN₂/LAr | 20 | 11450 | Φ2600×7655 |
| 1.6 | LOX/LN₂/LAr | 30 | 15790 | Φ2600×10605 |
| 1.6 | LOX/LN₂/LAr | 50 | 26500 | Φ3200×11670 |
| 1.6 | LOX/LN₂/LAr | 100 | 53300 | Φ3600×16550 |
| 2.16 | LCO₂ | 5 | 5200 | Φ1900×5115 |
| 2.16 | LCO₂ | 10 | 7860 | Φ2200×6030 |
| 2.16 | LCO₂ | 15 | 10087 | Φ2400×7020 |
| 2.16 | LCO₂ | 20 | 12740 | Φ2500×8120 |
| 2.16 | LCO₂ | 30 | 17165 | Φ2900×8550 |
| 2.16 | LCO₂ | 50 | 28644 | Φ3100×11500 |
| 2.16 | LCO₂ | 100 | 57550 | Φ3500×16450 |
| 2.16 | LCO₂ | 150 | 82460 | Φ3900×19000 |
Structure and Materials
Cryogenic liquid storage tanks usually adopt a double-layer structure. The inner tank is used to hold cryogenic liquids, while the outer tank plays a role in protection and heat insulation. The space between the inner and outer tanks is filled with high-performance thermal insulation materials, such as vacuum powder or multi-layer insulation materials, to reduce heat transfer and liquid evaporation. The inner tank is mostly made of stainless steel or aluminum alloy. These materials have good low-temperature toughness and corrosion resistance, and can withstand pressure changes at extremely low temperatures. The outer tank is usually made of carbon steel or stainless steel to provide structural support and external protection.
Thermal Insulation Performance
Thermal insulation is the core characteristic of cryogenic liquid storage tanks. Since cryogenic liquids are extremely prone to evaporation when heated, the thermal insulation design of the storage tank directly affects the storage time and economy of the liquid. Common thermal insulation methods include high-vacuum insulation, multi-layer reflective screen insulation and powder insulation. These methods can significantly reduce heat conduction and convection, keeping the liquid in a low-temperature state. For example, the daily evaporation rate of some storage tanks can be controlled at a low level, which means that the liquid can be stored for a long time without frequent replenishment.
Safety Features
Safety is an important consideration in the design of cryogenic liquid storage tanks. Storage tanks are usually equipped with multiple safety devices, such as pressure relief valves, explosion-proof discs and liquid level gauges. The pressure relief valve can automatically exhaust when the internal pressure is too high to prevent the tank from bursting; the explosion-proof disc serves as a backup safety measure to protect in extreme cases. The storage tank is also equipped with a temperature monitoring and alarm system to monitor the internal state in real time and ensure safe operation. When in use, specifications should be followed to avoid overfilling or exposure to high-temperature environments.
For details on specific specifications of the storage tank: Welcome to contact us, and we will respond to your inquiry promptly!
Email: info@gneeheatex.com
WhatsApp: +8615824687445
Product Tags:
|
|
ASME Certified Cryogenic Storage Tank 5000L 3MPa Horizontal Images
|
